精卫
-
> 完全自主研发的主控芯片
> 自主研发Tensor ECC®纠错算法
> 最高可达顺序读3.2GB/s，顺序写2.0GB/s
> 支持8通道，最大支持8TB的容量
> 适配SLC/MLC/TLC/QLC
> 支持SHA256/RSA2048/TRNG硬件加密
> 支持SM2/SM3/SM4加密算法
规格参数
| 芯片参数 | |
|---|---|
| Applications | UFS |
| 容量 | up to 256 GB |
| Host interface | UFS2.1 x 1-Lane |
| NAND interface | 2 channels, 4 chip selects (total 8 CEs) |
| NAND types | ONFI 3.2 / Toggle 3.0 1.2/1.8V Flash I/O with up to 533MT/s per channel TLC, 1z nm, 3D-NAND 1/2/4 planes and page size 8KB/16KB |
| CPU | single-core 32bit CPU |
| 性能 | Sequential Read 480 MB/s (maximum) Sequential Write 480 MB/s (maximum) |
| 数据保护与可靠性 | Support data security erase and quick erase LDPC algorithm for error correction Read-retry Global wear leveling Garbage collection Read disturb protection Data retention protection Software/Hardware write protect option Data integrity under power cycling |
| 温度 | Operating Temperature：-25°C to 85°C Storage Temperature：-40°C to 85°C |
